PVC Suction Hose
PVC Suction Hose
PVC suction hose is the best choice for water pumps in agriculture. With a reinforced PVC, the plastic suction hose is abrasion resistant and more durable. While it can withstand both positive and negative pressure.
Suction Pipe For Water Pump Structure
Tube & Cover: High quality pvc with rigid pvc helix
Temperature: -10℃ to +65℃ (14℉ to +150℉)
Application: Suction hose pipe is designed for regular water supply and drainage to transport various powdery particles and liquids. It is widely used in civil and building works, agriculture, mining, construction, shipbuilding and fishery.
Flexible Suction Hose Pipe is commonly seen on pumps and many industries. It is a non-marking, lightweight, mild abrasion and chemical resistant hose which is easy to handle and typically used in lighter duty applications.
The clear Suction Hose permits excellent visibility and its smooth exterior and interior allow for maximum flow of products. This hose is not suitable for transferring fuels and is also FDA approved for potable water.
PVC Water Suction Hose Features
Smooth inner construction for unrestricted flow of materials
Constructed with rigid spiral helix
Small bending radius
Impact & crush resistant
Abrasion & chemical resistant
Economical & flexible
PVC Suction Hose Specification
| I.D | OD | Thickness | W.P(at20˚C) | Vacuum Rat | Bend Radius | Length | ||
| inch | mm | mm | mm | bar | psi | mmHg(68˚F) | mm | m |
| 3/4" | 19.0±0.5 | 23.0±0.5 | 2.0 | 4.0 | 58 | 750 | 70 | 50 |
| 1" | 25.4±0.5 | 29.4±0.5 | 2.0 | 4.0 | 58 | 750 | 70 | 50 |
| 1-1/4" | 31.7±0.5 | 36.7±0.5 | 2.5 | 4.0 | 58 | 750 | 90 | 50 |
| 1-1/2" | 38.1±0.5 | 44.1±0.5 | 3.0 | 4.0 | 58 | 750 | 110 | 50 |
| 2" | 50.8±1.0 | 56.8±1.0 | 3.0 | 4.0 | 58 | 750 | 150 | 50 |
| 2-/2" | 63.5±1.0 | 69.5±1.0 | 3.0 | 3.0 | 44 | 750 | 180 | 50 |
| 3" | 76.2±1.0 | 83.2±1.0 | 3.5 | 3.0 | 44 | 750 | 220 | 50 |
| 4" | 101.6±1.5 | 109.6±1.5 | 4.0 | 3.0 | 44 | 750 | 330 | 50 |
