Coiled Air Hose
Coiled Air Hose
Coiled air hose is a special pneumatic air hose. It is in a coil shape and it it is highly compressible. Such hose widely serves in the vehicles like truck as air brake line. Besides, pneumatic coil hose is ideal for various pneumatic tools.
Coiled Air Hose
Material: Nylon, Polyurethane
Temperature: -40℃ to +80℃ (-40℉ to +176℉)
Application: coil hose pipe is used for air braker, automated machinery, coating machinery, all kinds of pneumatic tools, pneumatic & hydraulic machinery, construction and various pneumatic tools. Polyether based PU tube is hydrolysis resistant, anti-bacterial & anti-fungous, and it can be used for gardening, cleaning and other purposes as water hoses.
Nylon Tube And Coil/PU Coil Hose
Nylon Tube And Coil/PU Coil Hose has a smooth inner wall, fast air brake response, small pressure loss, abraion resistance, aging resistance and good flexibility. Coiled air line is widely used in air braker, automated machinery, coating machinery, pneumatic & hydraulic machinery, construction and various pneumatic tools. The work temperature range is from -40℃ to 80℃.
Coiled Air Hose Features
- Good elasticity, easy to operate, save space
- Absorbing impact and reduce the rub
- Customized specifications and sizes available
- Nontoxic and odourless
- Excellent flexibility
- Small bending radius
PU Coil Hose
| ID | OD | WP | BP | L | ||
| mm | mm | psi | bar | psi | bar | m/pc |
| 5 | 8 | 116 | 8 | 348 | 24 | 6 |
| 5 | 8 | 116 | 8 | 348 | 24 | 9 |
| 5 | 8 | 116 | 8 | 348 | 24 | 12 |
| 5 | 8 | 116 | 8 | 348 | 24 | 15 |
| 6.5 | 10 | 116 | 8 | 348 | 24 | 6 |
| 6.5 | 10 | 116 | 8 | 348 | 24 | 9 |
| 6.5 | 10 | 116 | 8 | 348 | 24 | 12 |
| 6.5 | 10 | 116 | 8 | 348 | 24 | 15 |
| 8 | 12 | 116 | 8 | 348 | 24 | 6 |
| 8 | 12 | 116 | 8 | 348 | 24 | 9 |
| 8 | 12 | 116 | 8 | 348 | 24 | 12 |
| 8 | 12 | 116 | 8 | 348 | 24 | 15 |
| 12 | 16 | 116 | 8 | 348 | 24 | 12 |
| 12 | 16 | 116 | 8 | 348 | 24 | 15 |
PU Coil Hose
| ID | OD | WP | BP | L | ||
| mm | mm | psi | bar | psi | bar | m/pc |
| 4 | 6 | 276 | 19 | 827 | 57 | 3m,6m,9m, 12m,15m |
| 6 | 8 | 276 | 19 | 827 | 57 | |
| 7 | 10 | 276 | 19 | 827 | 57 | |
| 9 | 12 | 276 | 19 | 827 | 57 |
